Used7PERKINS CASE SR130B Skid Steer Loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this skid steer
AHS Group has this PERKINS 404D-22 available at NSW.
As listed, it has an operating weight of 2,344 kg.
AHS Group has not published a price for this skid steer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | PERKINS |
| Model | 404D-22 |
| Condition | Used |
| Name | SR130B |
| Overall Height w/ LPE Bkt | 3,859 mm |
| Bucket Hinge Pin | 2,845 mm |
| Top Of ROPS | 1,919 mm |
| Bottom of Bkt Fully Raised | 2,682 mm |
| Length w/o Attachment | 2,435 mm |
| Length w/ LPE Bkt | 3,297 mm |
| Dump Angle | 40.2 ° |
| Dump Height w/ LPE Bkt | 2,073 mm |
| Dump Reach w/ LPE Bkt | 675 mm |
| Max Rollback at Ground | 26.12 ° |
| Max Rollback Fully Raised | 95.2 ° |
| Wheelbase | 941 mm |
| Ground Clearance | 178 mm |
| Angle of Departure | 22 ° |
| Rear Axle to Bumper | 858 mm |
| Overall Width (Spec Tyre) | 1,518 mm |
| Rated Operating Capacity 50% | 590 kg |
| Tipping Load | 1,179 kg |
| Lift Cylinder Breakout Force | 12.7 kN |
| Bucket Cylinder Breakout Force | 18.6 kN |
| Engine Brand | PERKINS |
| Engine Model | 404D-22 |
| Displacement | 20.4 cc |
| Horsepower Gross | 36.4 kW (48.8 hp) |
| Peak torque | 143 N·m |
| Low Range | 12.7 Km/h |
| High Range (Optional) | 18 Km/h |
| Pump flow 100% | 59 Lpm |
| Operating Weight | 2,344 kg |
| Shipping Weight | 2,160 kg |
| Fuel Tank | 60.5 L |
| Location | NSW |
| Category | Skid Steers |
Learn more about the CASE SR130B radial lift skid steer. This versatile machine features a 36.4 kW engine , a 590-kg operating capacity and an 18.6 kN bucket breakout force. Full description on the dealer's site →
