Used12KUBOTA D1105-EF09 UME22 Mini Excavator from UHI, (UME22) - UHI Machinery Aus

About this excavator
UHI Machinery has this UME22 Kubota D1105-EF09 available at VIC.
Full photos, the dealer's own description and any additional detail are on UHI Machinery's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | UME22 |
| Model | Kubota D1105-EF09 |
| Condition | New |
| Operating weight | 2,200 kg |
| Standard bucket capacity | 0.029 m³ |
| Engine model | Kubota D1105-EF09 |
| Displacement | 1.123 L |
| Rated power | 14 kW / 19 hp |
| Maximum torque | 67.4 Nm |
| Fuel capacity | 18 L diesel |
| Travel speed | 3.3 / 2.2 km/h |
| Swing speed | 10.5 rpm |
| Maximum gradeability | 30° |
| Hydraulic flow | 39.6 L/min |
| Operating pressure | 22 MPa |
| Ground-level digging radius | 3,610 mm |
| Maximum digging radius | 3,700 mm |
| Maximum digging depth | 2,150 mm |
| Maximum digging height | 3,275 mm |
| Maximum dumping height | 2,310 mm |
| Maximum vertical digging depth | 1,740 mm |
| Minimum turning radius | 1,580 mm |
| Maximum blade lifting height | 275 mm |
| Maximum blade digging depth | 180 mm |
| Wheelbase | 1,230 mm |
| Track length | 1,590 mm |
| Platform ground clearance | 473 mm |
| Tail turning radius | 885 mm |
| Chassis width | 990 / 1,240 mm |
| Track width | 230 mm |
| Track height | 360 mm |
| Transport length | 3,475 mm |
| Seat-to-floor height | 1,750 mm |
| Overall height | 2,300 mm |
| Boom offset - left | 390 mm |
| Boom offset - right | 510 mm |
| Full parts and labour warranty | 1 year |
| Engine full parts and labour warranty | 2 years |
| Full parts warranty | 3 years |
| Stock number | UME25-1 |
| Location | VIC |
| Category | Excavators |
Discover the UHI UME22 2.2 Ton Mini Excavator with a 19HP Kubota engine, Hydraulic Quick Hitch, 8 attachments, 3 Year Warranty and finance available. Full description on the dealer's site →
