Used7CASE Minotaur DL550 compact dozer loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this dozer
A Case Minotaur DL550 compact dozer loader offered by AHS Group in NSW.
As listed, it has a FPT F5B FL413 D engine.
AHS Group has not published a price for this dozer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Case |
| Model | Minotaur DL550 compact dozer loader |
| Condition | Used |
| Name | DL550 |
| Engine | FPT F5B FL413 D |
| Gross Horsepower | 85 kW (114.0 hp) |
| Net Horsepower | 85 kW (114.0 hp) |
| Peak Torque | 460 Nm |
| Displacement | 3.4 L |
| Emissions Certification* Solutions | Tier 4 Final Certified (SCR, DOC) |
| Drawbar Pull – Steel | 11,739 kg |
| Drawbar Pull – Rubber | 7,116 kg |
| Rated Operating Capacity (ROC) 35% | 1,750 kg |
| Rated Operating Capacity (ROC) 50% | 2,500 kg |
| Tipping Load | 4990 |
| Bucket Breakout Force | 57.4 kN |
| Standard Enhanced Flow Hydraulics | 157 L/min |
| Straight Blade Width | 2.44 m |
| Ripper Cut Width | 1.32 m |
| Height to Bucket Hinge Pin | 3.56 m |
| Dump Height with Heavy-Duty Bucket | 2.77 m |
| Height to Top of ROPS | 2.15 m |
| Overall Length with Blade w/o Ripper | 4.29 m |
| Overall Length with Blade with Ripper | 4.86 m |
| Overall Length with Heavy-Duty Bucket | 4.04 m |
| Track Length on Ground (Rubber) | 1.88 m |
| Location | NSW |
| Category | Dozers |
Dominate the jobsite with the CASE Minotaur™ DL550. Our site-ready package includes a standard hitch, factory bucket, mud bucket, and full civil specifications. Experience true doz… Full description on the dealer's site →
