Used7FPT CASE SR240B Skid Steer Loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this skid steer
AHS Group has this FPT F5H FL463 A*G001 available at NSW.
As listed, it has an operating weight of 3,350 kg.
AHS Group has not published a price for this skid steer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | FPT |
| Model | F5H FL463 A*G001 |
| Condition | Used |
| Name | SR240B |
| Overall Height w/ LPE Bkt | 4,070 mm |
| Bucket Hinge Pin | 3,180 mm |
| Top Of ROPS | 2,000 mm |
| Bottom of Bkt Fully Raised | 3,000 mm |
| Length w/o Attachment | 2,980 mm |
| Length w/ LPE Bkt | 3,710 mm |
| Dump Angle | 38.1 ° |
| Dump Height w/ LPE Bkt | 2,500 mm |
| Dump Reach w/ LPE Bkt | 570 mm |
| Max Rollback at Ground | 30.7 ° |
| Max Rollback Fully Raised | 99.7 ° |
| Wheelbase | 1,320 mm |
| Ground Clearance | 200 mm |
| Angle of Departure | 23.5 ° |
| Rear Axle to Bumper | 1,030 mm |
| Overall Width (Spec Tyre) | 1,770 mm |
| Rated Operating Capacity 50% | 1,088 kg |
| Tipping Load | 2,177 kg |
| Lift Cylinder Breakout Force | 25 kN |
| Bucket Cylinder Breakout Force | 39.4 kN |
| Engine Brand | FPT |
| Engine Model | F5H FL463 A*G001 |
| Displacement | 36.6 cc |
| Horsepower Gross | 55 kW (73.8 hp) |
| Peak torque | 314 N·m |
| Low Range | 11.3 Km/h |
| High Range (Optional) | 16.9 Km/h |
| Pump flow 100% | 91.5 Lpm |
| Operating Weight | 3,350 kg |
| Shipping Weight | 3,200 kg |
| Fuel Tank | 96.5 L |
| Location | NSW |
| Category | Skid Steers |
Learn more about the high-capacity CASE SR240B radial lift skid steer loader. It features a 55 kW engine, a 1,088-kg rated operating capacity and a massive 39.4 kN bucket breakout… Full description on the dealer's site →
