Used7FPT CASE SV340B Skid Steer Loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this skid steer
AHS Group has this FPT F5B FL413D*C001 available at NSW.
As listed, it has an operating weight of 4,136 kg.
AHS Group has not published a price for this skid steer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | FPT |
| Model | F5B FL413D*C001 |
| Condition | Used |
| Name | SR340B |
| Overall Height w/ LPE Bkt | 4,220 mm |
| Bucket Hinge Pin | 3,340 mm |
| Top Of ROPS | 2,040 mm |
| Bottom of Bkt Fully Raised | 3,170 mm |
| Length w/o Attachment | 3,020 mm |
| Length w/ LPE Bkt | 3,770 mm |
| Dump Angle | 46.7 ° |
| Dump Height w/ LPE Bkt | 2,590 mm |
| Dump Reach w/ LPE Bkt | 690 mm |
| Max Rollback at Ground | 35 ° |
| Max Rollback Fully Raised | 86.2 ° |
| Wheelbase | 1,320 mm |
| Ground Clearance | 240 mm |
| Angle of Departure | 23.5 ° |
| Rear Axle to Bumper | 1,080 mm |
| Overall Width (Spec Tyre) | 1,880 mm |
| Rated Operating Capacity 50% | 1,545 kg |
| Tipping Load | 3,090 kg |
| Lift Cylinder Breakout Force | 30.3 kN |
| Bucket Cylinder Breakout Force | 42.4 kN |
| Engine Brand | FPT |
| Engine Model | F5B FL413D*C001 |
| Displacement | 36.6 cc |
| Horsepower Gross | 67 kW (89.8 hp) |
| Peak torque | 383 N·m |
| Low Range | 12.4 Km/h |
| High Range (Optional) | 18.5 Km/h |
| Pump flow 100% | 91.5 Lpm |
| Operating Weight | 4,136 kg |
| Shipping Weight | 3,890 kg |
| Fuel Tank | 96.5 L |
| Location | NSW |
| Category | Skid Steers |
Experience the flagship power of the CASE SV340B vertical lift skid steer loader. It delivers a massive 1,545-kg rated operating capacity, a 67 kW engine and a best-in-class 3,343-… Full description on the dealer's site →
