Used9Kubota KX057-4 Excavator | Strong & Reliable
AHS Group·NSW
8 photos supplied by AHS Group and displayed from their website. See the original listing →
About this excavator
A Kubota Kubota V2607-DI offered by AHS Group in NSW.
AHS Group has not published a price for this excavator — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Kubota |
| Model | Kubota V2607-DI |
| Condition | Used |
| Name | KX057-4 |
| Engine Type | Interim Tier 4 Emission Level |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Engine Model | Kubota V2607-DI |
| Engine Net | 45.4 HP |
| Engine Gross | 47.6 HP |
| Displacement | 2,615 cc |
| Rated Speed | 2,200 rpm |
| Max. Traction Force | 6,567 kgf |
| Tumbler Distance | 1,990 mm |
| Crawler Length | 2,500 mm |
| Shoe Width | 400 mm |
| Ground Contact Pressure - Cab (Per cm2) | 0.32 kgf |
| Hydraulic Pump Capacity | 56.1 variable x2 / 37.0 Gear x 1 l/min |
| Aux Hydraulic Flow - AUX1 | 75 l/min |
| Aux Hydraulic Flow - AUX2 | 75 l/min |
| Max. Breakout Force - Bucket | 4,315 kgf |
| Max. Breakout Force - Arm | 2,500 kgf |
| Swing System | Conventional Swing |
| Unit Swing Speed | 9.3 rpm |
| Boom Swing Angle Left | 70 degree |
| Boom Swing Angle Right | 55 degree |
| Low | 2.8 km/h |
| High | 4.9 km/h |
| Length | 5,520 mm |
| Width | 1,960 mm |
| Height - Canopy | 2,550 mm |
| Height - Cab | 2,550 mm |
| Min. Ground Clearance | 310 mm |
| Operating Weight - Canopy | 5,510 kg |
| Operating Weight - Cab | 5,600 kg |
| Blade Width | 1,960 mm |
| Blade Height | 410 mm |
| Max. Lift Above Ground | 440 mm |
| Max. Drop Below Ground | 405 mm |
| Fuel Reservoir | 75 l |
| Hydraulic Oil Reservoir | 45 l |
| Hydraulic Oil System | 79 l |
| Engine Oil | 9 l |
| Operator Station | Canopy and Cab |
| Max. Digging Height | 5,820 mm |
| Max. Dumping Height | 4,160 mm |
| Max. Digging Depth | 3,890 mm |
| Max. Vertical Digging Depth | 3,100 mm |
| Max. Digging Radius At Ground | 6,130 mm |
| Max. Digging Radius | 6,260 mm |
| Min. Turning Radius - w/o Swing | 2,420 mm |
| Min. Turning Radius - Swing | 2,005 mm |
| Min. Tail Turning Radius | 1,270 mm |
| Location | NSW |
| Category | Excavators |
The Kubota KX057-4 compact excavator is built for superior strength and reliability. Find high-performance mini excavators for sale today. Full description on the dealer's site →
